Volume x 503 BMX - Voyager XL Frame Rose Gold

Limited Edition Colorway in collaboration with 503 BMX. Rose Gold Voyager XL with Pink Decals. Get em' while you can!

• Voyager XL Frame (503 BMX Collab)
• Top Tube:  20.75" or 21"
• Chainstay: 13″
• BB height: 11.7″
• BB Width: 74mm
• Seat Tube height: 9.25″
• Head Tube Angle: 75.25°
• Seat Tube Angle: 71°
• Seat Post: 25.4
• Headtube: Integrated (45°X45° Campy Spec)
• Brake Mounts: Removable Seatstay Mounts
• Dropouts: Heat Treated, 6mm thick with built in chain tensioners. Clears hub guards and pegs of all sizes.
• Color: Rose Gold
• Weight: 5 lbs 2 oz (21″)
• Warning! Returns for frames that have been used/installed are NOT accepted.

Powdercoated and stickered by 503 BMX out of Nampa, ID. This is a Limited Edition colorway for the existing Voyager XL Frame.

The Voyager XL frame features the same tech feel of the Voyager V2, but with a little extra length. It has a 75.25º heat tube, longer 13” slammed chainstay (13.25” center to center), and a 9.25” seat tube height. This frame also features double butted 4130 heat treated chromoly tubing, hour glass head tube, and small/clean 6mm thick laser cut and welded dropouts with built in chain tensioner. Added top and bottom gussets for strength, removable brake mounts, and S chainstays for bigger tire clearance.
